Plaster Spraying Gun

Plaster Spraying Gun

Product Details:


Product Description

We have achieved a distinct position in the market by providing Plastering Spraying Gun. This power trowel is given to our patrons in various specifications & widely admired for its performance. The power trowel offered by us is designed using modern technology as per with the quality standards. Moreover, we offer this power trowel to our patrons after assuring that the offered range is the best in quality and performance.


  • Noiseless functioning
  • Easy to operate
  • Robust structure

Technical Specification

Technical data

PFT G 4 smart

Part No.

00 25 73 59

Conveying capacity*

Approx. 6 – 85 l/min1

Pump capacity*

Approx. 22 l/min with D 6–3 mf

Conveying pressure*

Max. 30 bar

Conveying distance*

up to 50m


 Pump motor:

Star wheel motor:

2 geared motors

400 V, 50 Hz, 3 Ph

5.5kW, approx. 385 rpm

0.75kW, approx. 28 rpm

Air compressor

400 V with pressure switch-off

Compressor output

0.9kW, approx. 250 l/min, max. 4 bar

Water connection

3/4“, 2.5 bar when the machine is running

Water pressure booster pump

0,37 kW, 400 V

Dimensions / Weights

Filling height

910mm Hopper content:145 l







Total weight

Approx. 271 kg




* Tips on getting accurate quotes. Please include product name, order quantity, usage, special requests if any in your inquiry.
